MTL8000 2/2 Modules

All I/O modules are connected to a high speed Bus Interface Module (BIM) via a proprietary bus system called 'Railbus' and one BIM can control up to 32 modules. The module carrier provides the transmission medium for the Railbus and by plugging a module onto a carrier, connections are made between the module and the bus. The connectors on the carrier also provide the power supply links to the module.

For product certificates <click here>

Product Code Description Downloads

intrinsically safe logo Symbol denotes that the equipment is suitable for use in hazardous area applications.
fsm logo Symbol denotes that the product has been assessed for functional safety applications

  I/O modules overview Datasheet
Analogue Input Modules
8101-HI-TX  8-channel, 4 - 20mA with HART Datasheet
8103-AI-TX  8-channel, 4 - 20mA Datasheet
8119-VI-05  8-channel, 1-5V Datasheet
Analogue Output Modules
8102-HO-IP  8-channel, 4 - 20mA with HART Datasheet
8104-AO-IP  8-channel, 4-20mA Datasheet
Discrete Input Modules
8109-DI-DC  8-channel, 24 V dc, isolated, sinking Datasheet
8110-DI-DC  8-channel, 24 V dc, non-isolated, module powered Datasheet
8111-DI-AC  8-channel, 115 V ac, isolated, sinking Datasheet
8112-DI-AC  8-channel, 115 V ac, non-isolated, module powered Datasheet
8113-DI-AC  8-channel, 230 V ac, isolated, sinking Datasheet
8114-DI-AC  8-channel, 230 V ac, non-isolated, module powered Datasheet
8121-DI-DC  16-channel, 24 V dc, non-isolated, module powered Datasheet
8122-DI-DC  16-channel, 24 V dc, isolated, sinking Datasheet
8125-DI-DC  32-channel, 24 V dc, non-isolated, module powered Datasheet
8127-DI-SE  32-channel, Sequence of Events, 24 V dc, non-isolated, module powered Datasheet
Discrete Output Modules
8115-DO-DC  8-channel, 2-60 V dc, non-isolated, module powered Datasheet
8116-DO-AC  8-channel, 20-265 V ac, non-isolated, module powered Datasheet
8117-DO-DC  8-channel, 2-60 V dc, isolated, unpowered Datasheet
8118-DO-AC  8-channel, 20-265 V ac, isolated, unpowered Datasheet
Pulse Input Modules
8123-PI-QU  2-channel, pulse/quadrature input Datasheet
THC and RTD modules
8105-TI-TC  4-channel, THC and mV Datasheet
8106-TI-RT  4-channel, RTD and W Datasheet
