EATON Crouse-Hinds series MTL products

MTL1000 range signal conditioners

7

Applications

A

CONTROL SYSTEM

Signal conversion

Many types of signals in the control of a plant exist. Conversion to a common type reduces the number of system card types and quantity

that are required. Converting low level signals also improves signal quality and gives better control.

A

V

CONTROL SYSTEM

Elimination of grounding fault currents

Where high power devices are installed significant ground potential differences can occur across the plant, especially under fault conditions.

Without isolation these fault currents and voltages can severely damage system control equipment. Signal isolation eliminates damage under

these conditions thus keeping the process and plant operational.

A

CONTROL SYSTEM

Noise reduction

Machinery is a major source of noise and interference. Signal isolation and conditioning reduces the effects of this interference on the

process signals. This in turn will improve product yield and reduce operating costs.

A

CONTROL SYSTEM

LOCAL PANEL

Signal repeat

There are many instances where signals need to be transmitted to more than one area of the plant or measuring elements. Signal

duplication with isolation provides the means to achieve this whilst maintaining isolation between the plant equipment.
