MTL8000 1/1 IS isolator

Please note that this product has been discontinued. The information contained on this page is for reference use only.

For more information on migrating or equivalent product options click here
For more information on our current products click here

The 856-IS-DP provides a barrier between RS485 and RS485-IS to interface Standard Profibus DP and Intrinsically Safe Profibus DP.

With two IS channels it enables two BIM modules to operate in redundant mode and will support up to 13 MTL8000 1/1 nodes on the segment.

The 859-PL-DP connector (see 856-IS-DP datasheet) is designed for use on the IS Profibus side of the interface and can provide appropriate termination at that end of the segment. Pull-up and pull-down resistors are available in the 856-IS-DP for biasing where necessary.

Product Code Description Downloads

intrinsically safe logo Symbol denotes that the equipment is suitable for use in hazardous area applications.
fsm logo Symbol denotes that the product has been assessed for functional safety applications

856-IS-DP   Profibus DP segment coupler Datasheet
